BioX Wearables

BioX Research Starter Kit featuring synchronized AAL-Band 2.0 Forearm and Lower Limb wearable sensors for movement analysis.
Professional unboxing of the BioX Research Starter Kit showing two FMG sensor units in a premium foam-padded box with cables.
BioX wearable sensors integrated with Windows software for real-time biofeedback and synchronized motion data collection.
Researcher using BioX Forearm and Lower Limb sensors simultaneously for synchronized biomechanical tracking in a lab environment.
Close-up of the patented 8-sensor FMG array on the BioX AAL-Band showing high-precision muscle contraction tracking technology.

The BioX Research Starter Kit is the ultimate solution for combining patented gesture and motion sensing for both upper and lower limbs. This kit features the AAL-Band 2.0 (Forearm) and the AAL Leg-Band 2.0, delivering over 90% accuracy in muscle intensity and motion tracking. Designed for seamless human-machine interaction, it is the premier choice for exoskeleton control, gait analysis, and advanced robotics research.

  • Full-Body Intelligence: Dual 8-sensor FSR arrays for synchronized muscle contraction data.

  • Precision 9-DOF Tracking: Integrated IMUs for high-fidelity orientation and velocity tracking of multiple limbs.

  • Low-Latency Performance: Reliable Bluetooth streaming for real-time Windows integration.

  • Industrial Grade: Built for robust, long-term use in both lab and field environments.

Notice: Due to high demand, expected delivery time is currently up to 2 weeks.

How to connect to Bluetooth : https://support.microsoft.com/en-us/help/15290/windows-connect-blu//etooth-device


đź“– Read the Official FMG Sensor User Guide

Related products

BioX Research Starter Kit | Forearm + Lower Limb

€1.345,00€1.076,00 ex. VAT

Free Shipping (Worldwide)
creditcards
Ordering for a lab or university? [Request a Quote]

Description

The BioX Research Starter Kit provides a comprehensive wearable solution for capturing synchronized upper and lower limb dynamics. By integrating Force Myography (FMG) with 9-DOF Inertial Measurement (IMU), this kit allows researchers to stream muscle contraction intensity, limb orientation, and movement velocity across the entire body in real-time.


## Hardware & Signal Integrity

Both units in the kit are engineered for high-fidelity data collection and seamless human-machine interaction:

  • Dual Sensor Arrays: 16x highly sensitive FSR sensors (8 per band) for precise muscle mapping and contraction force measurement.

  • Motion Intelligence: Integrated 9-degrees-of-freedom IMUs providing linear acceleration, magnetic fields, and Euler angles.

  • Onboard Processing: Powered by Xtensa® dual-core 32-bit LX6 microprocessors for zero-lag calibration and low-latency streaming.

  • Intelligent Power Management: Dynamic power scaling and auto-shutdown (20 seconds after removal) to ensure maximum lab efficiency.


## Technical Specifications Comparison
FeatureForearm BandLower Limb Band
Weight90 grams100 grams
Dimensions36cm x 5.5cm50cm x 6.5cm
Fitment (Circumference)22cm – 25cm35cm – 40cm
Battery Life~4 hours (Lithium)~4 hours (Lithium)
ConnectivityBluetooth SPPBluetooth SPP
CompatibilityWindows 10/11Windows 10/11

## Included in the Research Starter Kit:

  • 1x BioX AAL-Band 2.0 (Forearm)

  • 1x BioX AAL Leg-Band 2.0 (Lower Limb)

  • 2x Micro-USB to USB 2.0 Cables (0.5m)

  • Access to Official Research Suite & Documentation

For software integration and data streaming instructions, please refer to our FMG Sensor User Guide.
